DISTANCE : ≤1200km	ROAD CONDITIONS : Highways and National Highways
SPEED : ≤ 120km/h	LOAD : Standard Load
POSITION : Drive

Product Design: Benchmarking with world-class brands (B brand, G brand), Adopting mature and market tested design and construction technologies.

Design Concept: Adopting STOT technology to analyze the force and temperature fields of tires to achieve optimal profile design and tread pattern design.

Construction Characteristics : Four belts construction design+Triplex extruded sidewall design+Super abrasion resistant compound;

Special Process： long circulation of Cooling water to make sure of semi-parts clean, stable length and excellent adhesion;

Indepedent high-pressure air lines (dual air lines) in the building machine to ensure the inner profile reaching standard and carcass body ply turn up is stable.

Performance Characteristics：Excellent dynamic balance and uniformity, high wear resistance, low rolling resistance, forecasted mileage 500,000 kilometers

4 belts construction design: increased belt rigidity and reduced sinking rate. The grounding shape is more reasonablereducing shoulder seperation and tread seperation issues

Triplex-compouding sidewall design: provide sufficient flexure transition space, reduce heat generation and fexural fatigue aging effectively to improve mileage;

Long-wearing special tread compound: Nd-gold technology and supper abrasion carbon black improved wear performance and durabity performance

Premium Drive Tires Heavy Truck Tire DLA966

1.Our Moq is one 20GP container, you can choose different sizes loading in one container. We have whole series of TBR tires.

SIZE	PR	PATTERN	Tread Depth（mm）	Tread Width （mm）	Standard Rim	Max Load（kg）		Pressure（kpa）		Speed Grade
SIZE	PR	PATTERN	Tread Depth（mm）	Tread Width （mm）	Standard Rim	Single	Dual	Single	Dual	Speed Grade
11R22.5	16PR	DLA966	15	220	8.25	3000	2725	830	830	M
11R24.5	16PR	DLA966	15	220	8.25	3250	3000	830	830	M
295/75R22.5	16PR	DLA966	15	234	9.00	3000	2725	830	830	M

2.PROCESS EQUIPMENT

R&D 4.0

Meeting demands of customers is our final standard of testing

3.Production Process

Automatic apexing machine

◆ Reduce the manual mis-operation.

◆ On-line apexing enhances the adhesion of apex and bead-bundle.
◆ Improves the durability performance of bead assembly.
◆ Improve the quality of apex joint, dynamic balance and uniformity of tire.

Automatic apexing machine

◆ Reduce the manual mis-operation.

4.Technological advantages

Common tire mileage under standard use condition as following:

TT(Tube Type)tire: 60,000km to 100,000km

TL tire(Tubeless Type):150,000km to 200,000km

TL tire marked on sidewall by G indicates manufactured with high abrasionresistant compound formula : more than 350,000km.

Standard use conditions shown on sidewall of the tire, mileage variationsdepending on weather, temperature, road condition, loading, inflation pressure.driving skills and Vehicle performance ,etc.
