DISTANCE : ≤1000km	ROAD CONDITIONS : Highways and National Highways
SPEED : ≤ 120km/h	LOAD : Standard Load
POSITION : Drive

Product Design: Benchmarking with world-class brands (B brand, G brand), Adopting mature and market validated design and construction technologies.

Design Concept: Adopting FEA and STOT technology to analyze the force and temperature fields of tires to achieve optimal contour design and tread pattern design.

Construction Characteristics : Four belts construction design+Triplex-compouding extruded sidewall design+Super abrasion resistant compound;

Special Process： long circulation of Cooling water to make sure of semi-parts clean, stable length and excellent adhesion;

Indepedent high-pressure air lines (dual air lines) in the building machine to ensure the inner profile reaching standard and carcass body ply turn up is stable.

Performance Characteristics：High mileage, high wear resistance, more safety, low rolling resistance, predicted mileage 38W kilometers

tread seperation issues

4 belts construction design: increased belt rigidity and reduced sinking rate. The grounding shape is more reasonable,reducing shoulder seperation and

Triplex compouding sidewall design: provide suficient fiexure transition space, reduce heat generation and fexural fatique aging effectively toimprove mileage:

Reinforced bead ring design: load resistance performance improve 15%

Premium Drive Tires Heavy Truck Tire DLD398

1.Our Moq is one 20GP container, you can choose different sizes loading in one container. We have whole series of TBR tires.

SIZE	PR	PATTERN	Tread Depth（mm）	Tread Width （mm）	Standard Rim	Max. Load（kg）		Pressure（kpa）		Speed Grade
SIZE	PR	PATTERN	Tread Depth（mm）	Tread Width （mm）	Standard Rim	Single	Dual	Single	Dual	Speed Grade
11R22.5	16PR	DLD812	22	226	8.25	3000	2725	830	830	L
11R24.5	16PR	DLD812	22	226	8.25	3250	3000	830	830	L
295/75R22.5	16PR	DLD812	22	238	9.00	3000	2725	830	830	L

2.PROCESS EQUIPMENT

R&D 4.0

Meeting demands of customers is our final standard of testing

3.Production Process

Automatic apexing machine

◆ Reduce the manual mis-operation.

◆ On-line apexing enhances the adhesion of apex and bead-bundle.
◆ Improves the durability performance of bead assembly.
◆ Improve the quality of apex joint, dynamic balance and uniformity of tire.

Automatic apexing machine

◆ Reduce the manual mis-operation.

4.Technological advantages

Common tire mileage under standard use condition as following:

TT(Tube Type)tire: 60,000km to 100,000km

TL tire(Tubeless Type):150,000km to 200,000km

TL tire marked on sidewall by G indicates manufactured with high abrasionresistant compound formula : more than 350,000km.

Standard use conditions shown on sidewall of the tire, mileage variationsdepending on weather, temperature, road condition, loading, inflation pressure.driving skills and Vehicle performance ,etc.
